IND-4
Radial Off-the-road Tyre
Consinuction BIAS
Service Industrial Service
Reinforced bead and sidewall area provideexceptional durability.
Special tread compound enables less heat generationand additional scrub resistance.
Optimal rubber-to-void ratio provides better stabilitywhile deeper tread depths enhance traction.
| Size | Ply rating | TRA code | Rim | Section width (mm) | Overall diamter (mm) | Tread depth (mm) | 5km/h | 10km/h | Type | ||
| Load capacity（kg） | Inflation pressure（kPa） | Load capacity（kg） | Inflation pressure（kPa） | ||||||||
| 12.00-24 | 24 | IND-4 | 8.5 | 315 | 1245 | 40 | 11000 | 1000 | 10100 | 1000 | TT |
| 14.00-24 | 28 | IND-4 | 10.0 | 375 | 1420 | 53 | 14500 | 1000 | 13500 | 1000 | TT |
| 16.00-25 | 36 | IND-4 | 11.25/2.0 | 430 | 1550 | 65 | —— | —— | 13600 | 975 | TL |
| 18.00-25 | 40 | IND-4 | 13.00/2.5 | 500 | 1675 | 65 | 24600 | 1000 | 22900 | 1000 | TL |
